19 Inch CMOS A4 Documents Interactive Digital Signage RS232

Ask Lasest Price
Brand Name :	Topview
Model Number :	TD-T1913
Certification :	CE,FCC,ROSH,C-TICK
Price :	Negotiable
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	4000pcs per month
Delivery Time :	10-15days after payment

Add to Cart

Product Details
Company Profile

19 Inch CMOS A4 Documents Interactive Digital Signage RS232

19inch Self Service A4 documents and photos Printing Scan Form Filling Printer Kiosk

Optional modules

1. Bluetooth connection .
2. Barcode reader:1D or 2D barcode reader
3. Fingerprint scanner
4. Printer:Epson 80MM thermal printer with auto cutter or HP A4 size laser printer.
5. Card reader: IC card reader/magnetic card reader/rfid card reader ,etc.
6. Metal keybaord with trackball,stainless steel,waterproof,encrypted
7. Cash acceptor:InchCashcodeInch branded,with RS232 interface, DC12V power,accepts multi-currency
8. Coin acceptor:accepts mul-currency coins
9. Camera

Components	Brand / Model	Main Specifications
Industrial PC System	Industrial PC	Mother Board	Intel H81; Integrated Network card and Graphic card
		CPU	i5 4460
		RAM	4G
		SSD	120G
		Interface	14USB; 12COM; 1HDMI; 1VGA; 2LAN; 1PS/2; 1*DVI;
		PC Power Supply	GW-FLX300M 300W
Operation System		Windows 10 (without license)
Display+Touch screen	21.5"	Screen Size	21.5 inch
		Pixel Number	1920*1080
		Pixel pitch	250cd/m²
		Contrast	1000∶1
		Display Colors	16.7M
		Viewing Angle	89°/89°/89°/89°
		LED Life Time	Min. 30000hrs
		Touch point number	10 point
		Input mode	Finger or capacitor pen
		Surface hardness	≥6H
Document Scanner	Q800L	Document size	A4, A3
		Pixels	8 million (3264*2448)
		Output format	YUV, MJPG
		Amount of distortion	<1%
		Whiter balance	Auto
A4 Size printer	HP M405d	Printer Method	Laser printer
		Resolution	4800 x 600 dpi
		Print speed	38 pages per minute
		page box	250 pages
		Power	AC 220-240V(±10％),50/60Hz(±2Hz),2A
Camera	XH3519-3238-LED	Sensor type	1/2.7"CMOS
		Array size	1928*1088
		Pixel	3.0um*3.0um
		Maximum image transfer rate	1080P 30FPS
		AGC/AEC/Whiter balance	Auto
Power Supply	LRS-150-12	AC input voltage range	100‐240VAC
Power Supply	LRS-150-12	DC output voltage	12V
Power Transformer	SHJZ 500VA	parameter	110V to 220V 500VA
Speaker	HZ	Dual channel amplified speakers for Stereo , 8Ω 5W.

FAQ

1) Q: How about your product quality?

A: There are three inspections in our company. from materials, product procedure, spection before shipping.

2) Q: What payment methods your company accept?

A: We accept most ofthe payment methods,but mainly accept T/T,L/C,Western Union and MoneyGram.

3) Q: How long is the warranty time for your products?

A: Our officially promised warranty time is one whole year after delivery at best.

4) Q: I haven't done business with you guys before,how can i trust your company?

A:Our company specialize in digital signage for 8 years,which is longer than most of our fellow suppliers what'smore,we've got quite a lot authority certificates,for example,CE,RoHS,FCC , C-TICK,certificate.SGS I hope those above will be persuasive enough.

5) Q: what's the shipment terms and delivery time of your company?

A: Well, they depends on the quantity of your order.As you know ,we need time to manufacture the machines.but mostly ,the shipment time is 3-8 working days after delivery.For Delivery way, for Sample and Bulk order < 100KG, we will kindly suggestExpress and Air freight, when Air freight and Sea shipping for Bulk order >100KG.As for detailed cost, it depends on your final order.

6) Q: Do you give any discount ?

A: I'll surely try my best to help you get those by the best price and good service at the same time.

7) Q: I would like to ask you if it's possible to have my logo on the product.

A: We hope you know that our company Spectrum perfectly support customized logo service. But, we also hope you know that it's an extraservice,so a little bit extra service fee is needed
