32" 55" 280W 1920×1080 350cd/m2 PCAP Touch Screen Table

Ask Lasest Price
Brand Name :	Topview
Model Number :	T-4301
Certification :	CEE,FCC.ROSH,C-Tick
Price :	Negotiate
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	4000pcs per month
Delivery Time :	10-15days after payment

Add to Cart

Product Details
Company Profile

32" 55" 280W 1920×1080 350cd/m2 PCAP Touch Screen Table

Restaurant/coffee/Show Room 32/55inch PC Win10 waterproof interactive multi PCAP touch screen table kiosk

1)7H 4mm Tempered Glass,anti-breakage
2)Waterproof,anti-glare and anti-reflective,scratch resistance
3)Heat resistance,RFID card reader
4)1 year free guarantee

Model No.	TPV-D3215
Panel size	32"
Display area(mm)/mode	699.58mm *393.58mm
Aspect Ratio	16:9
Maximum resolution	1920×1080
Display color	16.7M
Pixel Pitch(mm)	0.282(H)×0.282(V)
Brightness (nits)	350cd/m2
Contrast	1000:1
Visual angle	178°/178°
Response time	5ms
Life(hrs)	>50,000(hrs)
Touch Panel	Infrared 2-6 points touch/Capacitive 10-16 points touch
Positioning accuracy	±2mms
Transmittance	≥92%
Hardness	7H
Click manner	double point/multi-point(optional)
Response time	≤8ms
Output Resolution	4096X4096
Life time	Single point more than 600 million time
Input and output
VGA input	2
CVBS input	2
YPbPr input	1
TV	1
	4
USB2.0	6
LAN	1
PC Audio	1
Audio input	1
Audio output	1
Speaker	2x10w
Video
Color system	PAL/NTSC/SECAM
Resolution support	480P/720P/1080P
OSD
Menu Language	Chinese/English
Computer
Motherboard	Intel H81
CPU	Intel Core i3 dual core
Graphcis card	Intergrated
Network card	Intergrated 10/100/1000M adaptive
Memory	4G DDR3
Hard Disk	128G SSD OR 500G SATA
WIFI/LAN	Support
Operate system	Windows 7/8/10
Power
Power supply	AC100V~240V,50/60Hz
Maximum power consumption	280W
Standby power consumption	5W
Temperature
Working temperature	0℃~50℃
Storage temperature	-10℃~60℃
Working humidity	20%~80%
Storage humidity	5%~95%
Appearance
Cabinet color/appearance	White, black, customized
Cabinet material	SPCC/Aluminum/Customized
Warranty	1year after shipping

Product Application

Business Product Promotional display	supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels,restaurants, travel agencies, pharmacy
Financial Organizations	Banks, negotiable securities, funds, insurance companies, pawnshops; Non-profit Organizations: Telecommunications, post offices, hospital, schools
Public Places	subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums,convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers
Entertainments	Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course

FAQ:
Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
